The crankshaft and bearings assembly, with pistons and connecting rods attached can now be lifted out of cylinder block for service or overhaul as outlined in the appropriate following paragraphs.Īssemble by following the procedures outlined in the ASSEMBLY paragraph. Crankcase half (17) and cylinder (16) are matched and align bored, and are available as an assembly. Use extra care not to spring the parts or to mar the machined, mating surfaces.
Remove the cap screws which retain end caps (2and6) to power head, remove center main bearing screw (S) then unbolt and remove crankcase half (17). M6-19), cylinder block cover plate (13) and transfer power cover (14) should be removed for inspection and cleaning. Place the unit on power head stand or equivalent and remove fuel pump, carburetor flywheel and magneto. Remove the two screws which secure fuel line check unit to lower cowl and nuts securing power head to lower unit then lift off the complete power head assembly. To remove the power head assembly, first remove the top cowl and disconnect stop switch wire, speed control linkage and choke linkage. MERCURY TWO CYLINDER MODELS POWER HEAD | RandR AND DISASSEMBLE When installing the thermostat, position with "Vee" slot in visible end up as shown. The thermostat is located beneath a separate housing on top, rear face of cylinder head as shown in Fig.
When cooling system problems are encountered, first check the thermostat to see that it is operating properly.Ĭheck the water inlet for plugging or partial stoppage, then if trouble is not corrected, remove the lower unit gearcase as outlined in LOWER UNIT section, and check the condition of water pump, water passages and sealing surfaces.
The water pump is mounted in the lower unit drive shaft housing (upper gearcase). All motors are equipped with a rubber impeller type water pump. The Old Outboard Motor Service Manual: Volume 2 by Clymer, covers engines from the following manufacturers:īook Excerpt: Old Outboard Motor Service Manual: Volume 2: 30hp and above prior to 1969
